SONY IMX214
Model
FL0214Temperature class
-20℃~65℃Ean
6971390274613Price
$ 440
Xilinx Zynq UltraScale+ MPSoC XCZU15EG FPGA Development Board
PANGOMICRO SoM Boards Logos2 Series PG2L100H optical fiber
PANGOMICRO SoM Boards Logos Series PGL50H Industrial grade domestic DDR3
4-channel Vehicle Video Acquisition Injection GMSL1/2 Video Output Input LPC FMC Subboard
ALINX Dual Channel 65MSPS 12bit AD Analog digital signal conversion module AD9238
Binocular Camera Module SONY IMX214 CMOS Sensor 13 Million Pixels MIPI Interface Standard FMC LPC Interface
CMOS Image Sensor Chip
SONY IMX214
Resolution
13Mega-Pixel （4208 × 3120）@30fps 4K2K@30fps, 1080p@60幀
Output Video Format
RAW10/8, COMP8/6
Interface
CSI-2 serial Data Output (MIPI 4 lane, compatible D-PHY standard V1.1)
Viewing Angle
80.7° ± 3° (Diag)
Focusing Mode
Motor Auto Focus
Focusing Distance
3.94 inch ~ infinity
Size Dimension
2.72 inch x 2.99 inch
Supporting FPGA Board
with FMC Connectors
Documents Provided
Schematic, FPGA Testing programs
FMC Interface
The warranty period of all products sold is 12 months, of which FPGA chips and LCD screens are wearing parts and are not covered by the warranty. All accessories and gifts are not covered under warranty.
