PGL25G
Model
P25GTemperature class
-40℃~85℃Price
$ 79
PANGOMICRO Titan2 PG2T390H FPGA Development Board Evaluation Boards & Kits PCIe fiber optic communication AXP391
PANGOMICRO Logos PGL50G FPGA Development Board Evaluation Boards & Kits HDMI video image processing PGL50G
PANGOMICRO Titan-2 PG2T390 FPGA SoM Core Board DDR4 Industrial Grade P390
PANGOMICRO Logos PGL12G FPGA Development Board Evaluation Boards & Kits HDMI Output Video Image Processing PGL12G
PANGOMICRO Logos PGL22G FPGA Development Board Evaluation Boards & Kits Learning board
Suitable for high-speed data communication, video image processing, high-speed data acquisition, security, communication, industrial control, power, consumer electronics, and other applications
內存 DDR3
QSPI FLASH
LUT4
Flip-Flops
All supporting materials are provided through Baidu Netdisk. After purchasing, please contact customer service to request them.
01. Installation of Pango Design Suite and modelsim
02. Led_ Test Flowing Water Lamp Experiment and Simulation
04. DDR3 Reading and Writing Test Experiment
05. IO testing experiment
FPGA Chip
PGL25G6IMBG324
DDR3
512MB, 16bit
QSPI FLASH
16MB
LUT4
27072
Flip-Flops
33840
Distributed RAM(Kbit)
242
Block RAM(18Kbit/塊)
60
Total Block RAMKbit)
1080
PLLs
4
APM(18*18)
40
Extended IOs
136
Voltage Adjustable IOs
102
LVDS
68
Speed Class
6
Working Temperature
Industrial Grade, Working Temperature -40°C~85°C
RAM
1 x 512MB DDR3, 16bit
QSPI Flash
1x 16MB QSPI FLASH, Used for FPGA Configuration File and User Data Storage
crystal Oscillator
50 Mhz Provide Reference Input Clock for FPGA
JTAG Interface
10 pin 2.54mm standard JTAG port for downloading and debugging FPGA programs
Uart Interface
1 USB Uart interface for communication with PC or external devices and USB power input
40-pin Expansion Port
Four 40 pin expansion ports (2.54mm spacing), including 34 IO ports, one 5V power supply, two 3.3V power supplies, and three GNDs, which can be connected to the backplane or ALINX module
Voltage Input
+5V DC, Connect the computer to USB power supply, or the backplane to+5V power supply
FPGA Core Board
1
Plastic Pillars
4
Mini USB cable
1
40 rows of pins
2
Size Dimension
2.95inch x 2.52inch
Number of Layers
Adopting an 8-layer PCB design with reserved independent power layer and GND layer
Provide Schematic(PDF), PCB(PDF), Size Dimension, Package and Reference Design, that to Accelerate the Development of products with Core Board
The warranty period of the main body of all sold products is 12 months, of which FPGA chips and LCD screens are wearing parts and are not covered by the warranty.
All accessories and giveaways are not covered by the warranty.
